fNIR Sensors 3000

Description

These functional near-infrared optical brain imaging forehead (prefrontal cortex) sensor pads connect to an fNIR Imager to provide real-time oxy-Hb, deoxy-Hb, and raw data values for each channel measurement area. Each sensor can be applied to a different subject—run multiple subjects from a single unit (additional cables may be required).

18-optode (2 near) full head forehead pad

• requires 2 sensor cables
• shielded: grounded layers of copper protect the signal lines from being corrupted by environmental Electro Magnetic waves
• RXFNIR-3000-18S ships with systems and is compatible with Imager 3000, 2000S/M or 1200
• RXFNIR-3000-18U is an under-helmet version that fits under existing HMDs
• to record 54 channels, use three (3) 18-optode sensors with required cables

6-optode (2 near) sensor pad

• compatible with Imager 3000 or 2000C/E/M/S

5-optode (1 near) sensor pad

• compatible with Imager 3000 or 2000C/E/M/S
