Isolated Digital Interface, MP30

Description

If you already have SuperLab and the Digital I/O card with the Support Pack, you can interface to the MP30 System using the STP30 interface. The STP30 interface connects between the SuperLab Digital I/O card and the BIOPAC MP30 acquisition unit.

The STP30 system provides 3 lines for digital data inputs; all lines are optically isolated to 1500 VDC compliance.

The STP30 system can also be used to connect digital signals (TTL compatible) from any mains powered external equipment to the MP30 when the system also connects to electrodes attached to humans.
